The Influence of Epoxy Resin Encapsulation on the Heat Dissipation Performance of LEDs and the Hazards of Poor Heat Dissipation

The Influence of Epoxy Resin Encapsulation on the Heat Dissipation Performance of LEDs and the Hazards of Poor Heat Dissipation



LED (Light Emitting Diode), as a new type of high-efficiency, energy-saving, and environmentally friendly light source, has been widely used in fields such as lighting and display. However, with the continuous increase in LED power, the heat dissipation problem has gradually become a key factor restricting its performance and lifespan. Epoxy resin encapsulation is an important link in the LED manufacturing process. It not only has a significant impact on the optical performance of LEDs but also affects the heat dissipation performance of LEDs to a large extent. In-depth research on the influence of epoxy resin encapsulation on the heat dissipation performance of LEDs and the hazards caused by poor heat dissipation is of great significance for improving the quality and reliability of LEDs.

Best structural epoxy adhesive glue manufacturers in china
Best structural epoxy adhesive glue manufacturers in china

The Influence of Epoxy Resin Encapsulation on the Heat Dissipation Performance of LEDs

(1) Thermal Conductivity of Epoxy Resin Material

Epoxy resin is a commonly used LED encapsulation material, and its thermal conductivity is relatively low. Generally speaking, the thermal conductivity of epoxy resin is between 0.1 – 0.3 W/(m·K), which is much lower than that of metal materials (for example, the thermal conductivity of copper is approximately 400 W/(m·k)) and some ceramic materials. This means that the heat generated during the operation of the LED is difficult to be conducted out quickly through the epoxy resin, resulting in heat accumulation around the chip. For example, in high-power LEDs, a large amount of heat generated by the chip, if not dissipated in a timely manner, will cause the chip temperature to rise rapidly, thereby affecting the performance of the LED.

(2) Influence of the Encapsulation Structure on Heat Dissipation

  1. Encapsulation Thickness: The thickness of the epoxy resin encapsulation has a significant impact on the heat dissipation of LEDs. A thicker encapsulation layer will increase the thermal resistance and hinder the heat transfer. When the encapsulation thickness increases, the heat needs to travel a longer path to be dissipated, which will lead to an increase in the chip temperature. Studies have shown that, under the same other conditions, for every 0.1mm increase in the encapsulation thickness, the chip temperature may rise by 2 – 5℃.
  2. Filling Method: The filling method of the epoxy resin also affects the heat dissipation performance. If the filling is uneven, it will lead to an increase in the local thermal resistance, and the heat cannot be dissipated evenly. For example, in some LEDs encapsulated by dispensing, if the amount of glue is not properly controlled, air bubbles or voids may be formed around the chip, and the thermal conductivity of these areas will be lower, thus affecting the overall heat dissipation effect.
  3. Connection with the Heat Dissipation Substrate: The LED chip is usually connected to the heat dissipation substrate through the die bonding adhesive, and the thermal conduction efficiency between the epoxy resin encapsulation and the heat dissipation substrate also affects the heat dissipation performance of the LED. If the contact between the two is poor or there is a large thermal resistance, the heat will be difficult to transfer from the chip to the heat dissipation substrate, thereby affecting the heat dissipation effect of the LED.

(3) Influence of the Aging of Epoxy Resin on Heat Dissipation

As the usage time increases, the epoxy resin will undergo aging. After aging, the performance of the epoxy resin will decline, such as a decrease in thermal conductivity and a deterioration of mechanical properties. The decrease in thermal conductivity will further weaken the heat dissipation ability of the epoxy resin, leading to an increase in the chip temperature. At the same time, aging may also lead to a decrease in the bonding force between the epoxy resin and the chip or the heat dissipation substrate, resulting in gaps or delamination, which will also increase the thermal resistance and affect the heat dissipation effect.



Hazards of Poor Heat Dissipation of LEDs

(1) Influence on the Optical Performance of LEDs

  1. Decrease in Luminous Efficiency: When the heat dissipation of the LED is poor, the increase in the chip temperature will cause a change in the energy band structure of the semiconductor material, thus reducing the recombination efficiency of electrons and holes and decreasing the luminous efficiency. Studies have shown that for every 10℃ increase in the LED chip temperature, the luminous efficiency may decrease by 5 – 10%. This means that under the same input power, the output luminous flux of the LED will decrease, and the lighting effect will deteriorate.
  2. Color Shift: The change in temperature will also affect the luminous color of the LED. As the chip temperature rises, the peak wavelength of the LED will shift towards the long-wave direction, that is, a red shift phenomenon occurs. This color shift will lead to a poor color consistency of the LED, which will affect the quality of the product in lighting and display applications. For example, in a display screen, if the color shift of the LED is too large, it will cause color distortion of the image.

(2) Influence on the Electrical Performance of LEDs

  1. Change in Forward Voltage: The forward voltage of the LED is closely related to the temperature. When the chip temperature rises due to poor heat dissipation, the forward voltage of the LED will decrease. This will cause a change in the operating current of the LED. If the driving circuit does not have corresponding adjustment measures, it may cause the operating current of the LED to exceed the rated value, thereby accelerating the aging and damage of the LED.
  2. Decrease in Reliability: High temperature will cause changes in the materials and structures inside the LED, such as the oxidation of the electrodes and the lattice distortion of the semiconductor material. These changes will lead to unstable electrical performance of the LED and a decrease in reliability. LEDs that work at high temperatures for a long time will have a significantly shortened lifespan and may even experience sudden failure.

(3) Influence on the Mechanical Performance of LEDs

  1. Deformation of the Encapsulation Material: The high temperature caused by poor heat dissipation will cause the epoxy resin encapsulation material to expand and deform. When the temperature changes repeatedly, the encapsulation material will experience cycles of thermal expansion and contraction, which will cause stress between the encapsulation material and the chip or the heat dissipation substrate. Long-term stress may cause cracks or delamination in the encapsulation material, affecting the mechanical stability of the LED.
  2. Failure of the Connection between the Chip and the Substrate: High temperature will also affect the connection between the chip and the heat dissipation substrate. For example, the die bonding adhesive may age and fail at high temperatures, resulting in a decrease in the connection strength between the chip and the substrate. This may cause the chip to shift or fall off during operation, making the LED unable to work properly.
Best water-based contact adhesive glue manufacturers
Best water-based contact adhesive glue manufacturers

Conclusion

Epoxy resin encapsulation has an important influence on the heat dissipation performance of LEDs. Factors such as its material characteristics, encapsulation structure, and aging will all lead to changes in the heat dissipation ability of LEDs. And poor heat dissipation of LEDs will have many hazards to its optical, electrical, and mechanical properties, seriously affecting the performance and lifespan of LEDs. In order to improve the quality and reliability of LEDs, in-depth research and improvement are needed in aspects such as the selection of epoxy resin encapsulation materials, the optimization of the encapsulation process, and the design of the heat dissipation structure. For example, developing epoxy resin materials with higher thermal conductivity, optimizing the encapsulation structure to reduce thermal resistance, and adopting effective heat dissipation measures to reduce the chip temperature. Only by solving the heat dissipation problem of LEDs can their advantages be fully utilized and the sustainable development of the LED industry be promoted. In future research, it is also necessary to further explore the complex relationship between epoxy resin encapsulation and LED heat dissipation in depth to provide more powerful technical support for the development of LEDs.
